Lenco Tactile Switch Kit with Pigtail for Single Actuator Systems

This tactile switch kit features a compact design ideal for consoles where space is limited. The kit includes a control box that requires separate mounting. The LED indicator lights provide clear feedback on the position of your trim tabs, while the backlit keypad offers visibility during nighttime operations. A photo eye automatically adjusts the LED brightness based on ambient light, ensuring optimal visibility in varying conditions.

Main Features:

• Quick and easy Plug & Play installation
• Instantaneous response to user inputs
• Integrated retractor mechanism
• Low profile construction
• Waterproof sealed keypad and control box with Deutsch connectors
• 36-inch pigtail for connecting to the control box
• Requires 2 1/16-inch cut-out; overall keypad dimensions are 2.75" x 2.75"
• 2.33 inches of clearance needed from the back of the keypad
• Two high-intensity LED indicators for precise trim tab positioning
• Photo eye for optimal visibility in all lighting
• Backlit keypad for nighttime visibility
• Self-Check feature for ongoing performance

Note: Replacement keypads and control boxes for 2016 and earlier switches are incompatible with this kit. Additional replacement parts are available separately.

Specifications:

• 3 Year Warranty
• System Type: Single Actuator
• Compliance: CE Certified

WARNING: This product may expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP), known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit P65Warnings.ca.gov.

• Quick and easy Plug & Play installation
• Instantaneous response to user inputs
• Integrated retractor mechanism
• Low profile construction
• Waterproof sealed keypad and control box with Deutsch connectors
• 36-inch pigtail for connecting to the control box
• Requires 2 1/16-inch cut-out; overall keypad dimensions are 2.75" x 2.75"
• 2.33 inches of clearance needed from the back of the keypad
• Two high-intensity LED indicators for precise trim tab positioning
• Photo eye for optimal visibility in all lighting
• Backlit keypad for nighttime visibility
• Self-Check feature for ongoing performance
