Blue Sea 8686 Dual-Battery m-Series, Dual Circuit Plus

Name: 8686 Blue Sea 8686 Dual-Battery m-Series, Dual Circuit Plus
Brand: Blue Sea Systems
SKU: XMQM7Y3N67
Price: 201.98 USD
Availability: InStock

MFG No: 8686
SKU No: XMQM7Y3N67
UPC: 632085086862
MFG. Name: Blue Sea Systems
Available: 3
Condition: New

$171.89

Blue Sea Dual Battery Bank Management Panel

Model: 8686-BSS

Isolates the Engine circuit from the House circuit
Allows emergency cross connect between isolated battery banks
Protects electronics from sags and spikes caused by engine cranking

Specifications

Maximum Voltage	48V DC
Continuous Rating	300A
Intermittent Rating	500A (5 min)
Cranking Rating 10 sec	1500A
Cranking Rating 1 min	775A
Height	7.50in (190.5 mm)
Width	4.50in (114.3 mm)
Depth	3.25in (82.55 mm)
Weight	1.85lb (0.84 kg)
Positions	4
Nominal Voltage	12V DC 24V DC
