Product Information

• Part Number: APDU9959NA3
• Manufacturer: APC by Schneider Electric
• Product Name: APC 20A 208V 21xC19/C15 3xC19/C21 L620 0U Rack PDU APDU9959NA3
• Model: APDU9959NA3
• Warranty: 2 years repair or replace

Product Description

The APC APDU9959NA3 is a 0U rack-mount power distribution unit (PDU) designed to provide reliable power distribution to multiple devices in a data center or server rack. It has a single 20A, 208V input and features a combination of C13, C15, C19, and C21 outlets to accommodate a wide range of IT equipment. The PDU's vertical, 0U form factor allows it to be mounted in the rear of a rack, saving valuable rack space. This basic PDU is an unmonitored solution for distributing power to critical IT equipment.

Product Specifications

• Nominal Input Voltage: 208V
• Input Frequency: 50/60 Hz
• Input Connection: NEMA L6-20P
• Output Receptacles: 18 x IEC 60320 C13, 3 x IEC 60320 C19, 2 x IEC C15, 1 x IEC C21
• Max Total Current Draw: 20A
• Cord Length: 10 ft (3.05 m)
• Color: Black
• Mounting: Vertical (0U)
• Dimensions (HWD): 72.0 x 2.2 x 1.7 inches (182.9 x 5.6 x 4.4 cm)
• Weight: 10.0 lbs (4.55 kg)

Output
Nominal Output Voltage :208V
Maximum Total Current Draw per Phase :20A
Output Connections:
(21) IEC 320 C13
(3) IEC 320 C19
Overload Protection :No Input
Nominal Input Voltage: 200V,208V,230V
Input Frequency :50/60 Hz
Regulatory Derated Input Current (North America) :16A
Input Connections :NEMA L6-20P
Cord Length: 9.84 feet (3 meters)
Number of Power Cords: 1
Acceptable Input Voltage: 200-240 VAC
Maximum Line Current per phase: 20A
Maximum Input Current per phase :20A Conformance
Regulatory Approvals: cUL Listed,EN 55022 Class A,EN 55024,EN 61000-3-2,EN 61000-3-3,FCC Part 15 Class A,ICES-003,PSE,UL Listed,VCCI Class A,VDE
Environmental Compliance: RoHS,REACH: Contains No SVHCs,Contains Lithium Battery Item Dimension (L"xW"xH"):
4.5 x 78.8 x 6.5

Weight:
18.90 lb

Warranty Information:
2 years repair or replace
