Fireboy Two-Zone Detection & Alarm Panel - 12/24V DC

This detection and alarm panel is designed for two zones, capable of supporting up to 14 smoke or heat detectors, along with rate of rise heat detectors connected to each zone (sold separately). Ideal for enhanced fire safety in various environments.

Key Features:

• Visual and audible fire or fault indicators
• Water-resistant display for durability
• Voltage and EMI protection included
• Reverse polarity protection for safety

Specifications:

• Supply Voltage: 9-32V DC
• Zone Loop Voltage: 24V DC (independent of input voltage)
• Minimum Alarm Current: 15mA
• Maximum Current Per Zone: 400mA
• Maximum Sensors Per Zone: 8
• EOL Resistor: 5.6kΩ
• Potential Free Transistor Output (Fault, Alarm): 50V max
• Relay Output (Buzzer): 2A

• Alerts for fire or system faults
• Durable, water-resistant display
• Protected against voltage and EMI issues
• Safety against reverse polarity
