MELLANOX CABLE MODULE, ETH 25GBE, 100GB/S TO 25GB/S, QSFP28 TO SFP28
Absolute Maximum Ratings
Supply voltage
-0.3V to 3.6V Data input voltage
-0.3V to 3.6V Control input voltage
-0.3V to 3.6V Storage temperature
-40 to 85^oC Operation Module Information
Supply voltage (Vcc)
Minimum: 3.135V
Typical: 3.3V
Maximum: 3.465V Power consumption
0.1W Operating case temperature
0 to 70^oC Electrical Module
Characteristic impedance: 90 110 Omega (Typical: 100 Omega) Description
Mellanox cable module, ETH 25GbE, 100Gb/s to 25Gb/s, QSFP28 to SFP28 Item Dimension (L inchxW inchxH inch)
NA Weight
0.05 lb Warranty Information
1 Year
