Accessories
Hardware
4K Support:Yes
Bus Type:USB-C
Chipset ID:VIA/VLI - VL813
MegaChips - STDP4320
Realtek - RTL8153
C-Media - CM6533
Texas Instruments - TPS65983
Displays Supported:2
Fast-Charge Port(s):Yes
Industry Standards:USB Power Delivery Specification Rev. 2.0
USB Battery Charging Specification Rev. 1.2
DisplayPort 1.2 with MST
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Performance
Auto MDIX:Yes
Compatible Networks:10/100/1000 Mbps
Full Duplex Support:Yes
Maximum Data Transfer Rate:5 Gbps (USB 3.0)
2 Gbps (Ethernet Full-Duplex)
Maximum Digital Resolutions:1920 x 1200p at 60Hz (HDMI/DVI - Dual Monitors)
4096 x 2160p at 24Hz (HDMI - Single Monitor)
3840 x 2160p at 30Hz (HDMI - Single Monitor)
1920 x 1200p at 60Hz (DVI - Single Monitor)
PXE:Yes
Type and Rate:USB 3.0 - 5 Gbit/s
UASP Support:Yes
Connector(s)
Connector Type(s):2 - USB Type-C (24 pin) USB 3.0 Female
2 - HDMI (19 pin) Female
1 - USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
3 - USB Type-A (9 pin) USB 3.0 Female
1 - RJ-45 Female
1 - 3.5 mm Mini-Jack (4 Position) Female
Software
OS Compatibility:Windows 7, 8, 8.1, 10
Special Notes / Requirements
Note:Ensure your laptops drivers, firmware, and operating system are up to date prior to using the docking station.
A 4K-capable HDMI display is required to achieve 4K resolution
Video output capabilities are dependent on the video card and hardware specification of your connected laptop. Certain video cards have limited MST support, while some monitors will also limit the available resolution.
Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your laptop USB-C port supports DP Alt Mode, as well as USB Power Delivery.
USB 3.0 is also known as USB 3.1 Gen 1 this connectivity standard offers speeds up to 5Gbps
Not all Thunderbolt 3 USB-C ports support the full functionality of the Thunderbolt 3 standard. Ensure that your laptop Thunderbolt 3 port supports USB Power Delivery.
Mac OS and Chrome OS do not support MST.
For a dual-monitor configuration, the Windows laptop must support MST
System and Cable Requirements:A Windows-based laptop with an available USB-C port (to ensure full adapter functionality, the host USB-C port must support USB Power Delivery 2.0 and DP Alt Mode)
Power
Center Tip Polarity:Positive
Input Current:2 A
Input Voltage:100 - 240 AC
Output Current:5 A
Output Voltage:20V DC
Plug Type:N
Power Consumption (In Watts):100 W
Power Delivery:60W
Power Source:AC Adapter Included
Environmental
Humidity:5%-95% RH (Non-condensing)
Operating Temperature:0^oC to 40^oC (32^oF to 104^oF)
Storage Temperature:-20^oC to 70^oC (-4^oF to 158^oF)
Physical Characteristics
Color:Black
Enclosure Type:Plastic
What is in the Box
Included in Package:1 - docking station
1 - 1m USB-C to USB-C cable
2 - HDMI to DVI adapters
1 - universal power adapter (NA/JP, ANZ)
1 - quick-start guide
Item Dimension (L inchxW inchxH inch)
12 x 8 x 3 Weight
3.31lb Warranty Information
3 Years
