The Adesso NuScan 5200TU is compatible with a wide range of 1D and 2D barcode symbologies. With CMOS imager the NuScan 5200TU is able to scan major 2D barcodes such as PDF 417, QR Codes, Data Matrix, and micro QR Code. As your daily peripheral companion, your peripheral must be able to provide you with good hygiene and cleanness. Built with waterproof and antimicrobial substances, the NuScan 5200TU can be cleaned periodically. Its 7 meter drop protection also adds to its ruggedness. With all these great features, the NuScan 5200TU is truly your ultimate barcode scanner.
Imager:
640 x 480 CMOS Light Source:
650 +/- 10 nm visible red LED and White LED Depth of Field:
0-12 inches (at20mil EAN-13, PC 100%) Scan Angle:
Roll: +/-50^o, Pitch: +/-45^o, Yaw: +/-360^o Motion Tolerance:
24 inches per second (IPS) Minimum Bar Width (1D):
5 mil/0.127 mm at PCS 90%, Code 39. Minimum Bar Width (2D):
10 mil/0.254 mm at PCS 80%, Data Matrix. Print Contrast:
PCS 30% code 39 at 5mil Indicators (LED):
Green LED Alert Operation:
Programmable Beeper Tone Input Voltage:
5VDC +/- 5% Operating Current:
220 +/- 5% mA Cable:
6 ft (1.83m) Operating Temperature:
-20^oC to 50^oC Storage Temperature:
-40^oC to 70^oC Humidity:
5% to 95% (non-condensing) Light Levels:
Max 100,000 lux Shock:
Withstanding 7m freefall drops Supported Symbologies
UPC-A/E
EAN13/8
Code 128
GS1-128
Code 39(Plain and Full ASCII)
Code 93
Code 11
Code 25(ITF/Industrial/Matrix/IATA Standard)
Codabar,
MSI/MSI Plessey
GS1 DataBar Item Dimension (L inchxW inchxH inch)
9 x 5 x 4

Weight
2.00 lb

Warranty Information
1 year
