ROUTER
WAN ports
2 RJ-45 Gigabit Ethernet
LAN ports
4 RJ-45 Gigabit Ethernet RV340, RV340W
Console/serial
1 RJ-45 port for future use. Port is disabled
USB
2 for external 3G/4G modem or flash drive (USB-3, USB-2)
Firewall
Stateful packet inspection, up to 980 Mbps throughput for TCP and UDP
Quality of Service (QoS)
Traffic Classes, WAN Queuing, WAN Policing, WAN Bandwidth Management, Assign detailed QoS (Class of Service (CoS)/Differentiated Services Code Point (DSCP)/policies) settings per application or end device
Web Security
Dynamic web filtering: Cloud based, more than 80 categories, more than 450 million domains classified
Application Visibility
Application identification: Assign policies to Internet applications
500 unique Apps
Client Identification
Identifies and categorizes clients dynamically. Assigns policies based on end device category and operating system.
Intrusion Prevention System
IDS/IPS inspects network packets, logs and/or blocks a wide range of network attacks. It delivers increased network availability, faster remediation, and comprehensive threat protection.
HTTP/FTP/SMTP/POP3/IMAP
Antivirus
Protection from viruses, trojans, spyware, and identity theft by inspecting traffic going through the router.
HTTP/FTP/SMTP/POP3/IMAP
Cisco Umbrella
First line of defense for threats on the Internet. Prevention for user and malware-initiated connections. Protection against Malware, C2 callbacks, and phishing. Proxy inspection for risky domains.
IPSec
IKEv1 and IKEv2
50 simultaneous connections (any combination of remote access and site-to-site), up to 650 Mbps throughput
IPsec remote access
Yes (remote access from any standards-based IPsec client and Cisco IPsec VPN EasyVPN)
Layer 2 Tunneling Protocol (L2TP) over IPsec
Yes
Generic Routing Encapsulation (GRE) over IPsec
Yes
Cisco SSL VPN (Cisco AnyConnect)
Maximum 50 SSL VPN tunnels and up to 33Mbps throughput. Also requires Cisco AnyConnect end user licenses to use on the end device. Ideal for mobile devices.
Point-to-Point Tunneling Protocol (PPTP)
25 connections, up to 100 Mbps throughput
Teleworker mode (Cisco IPsec VPN)
Router acts as a client to connect to central VPN gateway in teleworker mode
VPN pass-through
IPSec, PPTP, L2TP
Management protocols
Web browser (HTTP/HTTPS)
Simple Network Management Protocol (SNMP) v1, v2c, and v3
Representational State Transfer (REST) API
NETCONF
Management Platform
FindIT Network Manager
Firmware upgrade options
Via local PC, USB stick, or from Cisco.com via web browser.
Unattended automatic firmware upgrade.
LAN
VLAN
Up to 32 VLANs
Port Security
Yes, 802.1X
Link aggregation
Yes (static, no LACP)
IPv6
Dual stack, 6rd, 6in4, Dual stack lite
WAN
DHCP client, static IP, PPPoE, PPPTP, L2TP, transparent bridge
Routing
Static routing, IGMP proxy, Inter-VLAN routing, Routing Information Protocol RIPv1,v2, RIPng
Network Address Translation (NAT)
Port Forwarding
Port Address Translation (PAT)
One-to-one NAT
VPN NAT traversal
Session Initiation Protocol (SIP) Application-Level Gateway (ALG), FTP ALG
NAT max sessions
Greater than 40000
NAT max connections per second
3000
DynDNS
ChangeIP.com, DynDNS.com, No-IP.com, dnsomatic
IPv6 transition
Dual Stack
Hardware DMZ
Yes (when enabled, one LAN port will be DMZ port)
DMZ host
Yes
System
CPU
ARM-based architecture, dual core, hardware flow engine
1.2 Ghz (RV340W)
900 Mhz (RV345, RV345P, RV340)
RAM
1 GB DDR3
Flash
256 MB
Item Dimension ( L inchxW inchxH inch)
18 x 12 x 4 Weight
7 lb Warranty Information
NA
