Pacer 6 AWG Tinned Closed-End Lugs - 5/16" Size - 10 Pack

Creating a strong and reliable connection is crucial for any electrical system. Pacer's tinned closed-end lugs offer both durability and longevity, making them the ideal choice for marine and other demanding applications. With no exposed seams and a tin-plated finish, these lugs help create waterproof connections when combined with epoxy heat shrink.

To use, simply strip your wire or cable to the correct length, slide the lug onto the exposed wire ensuring the insulation is flush with the edge of the lug, and crimp it using the appropriate tool. For enhanced durability, consider adding epoxy-lined heat shrink. Pacer's closed-end lugs are compatible with wire sizes ranging from 8 AWG to 4/0 AWG and are available with various stud sizes including #10, 1/4", 5/16", 3/8", and 1/2". For expert advice on selecting the right lug, feel free to reach out to a Pacer expert.

• Tin-plated for enhanced protection
• No exposed seams for improved safety and performance
• Rated for 600V
• Constructed from seamless tubes of 99.9% copper for optimal conductivity
• Designed for stranded copper wires
• Larger pad area for superior contact
• Clear markings on pad for cable size and stud hole
• Can be crimped or soldered for versatility
• Controlled flare for easy cable insertion
• Tight barrel to pad transition for longer barrel length
