This surge suppressor is designed to provide safe, reliable surge protection in harsh environments. A high 3900-joule rating can protect connected equipment against even the strongest surges. Eight outlets protect connected equipment against damaging surges, spikes and line noise. Convenient transformer outlets accommodate multiple transformers without blocking other outlets. A 25-foot (7.6-meter) grounded cord with integrated cord clip reaches distant outlets. A lighted on/off switch with integrated circuit breaker provides power control over connected equipment. Breaker protects against dangerous system overload. Protected LED confirms that connected equipment is being protected. Four safety covers shield unused outlets from debris and accidental contact. A rugged metal case stands up to the harshest environments. Built-in cord wrap with hang holes provides convenient cord management. Integrated keyhole slots on bottom panel provide convenient wall/desk mounting. As an added safety feature, the surge suppressor's bright yellow color alerts you and others that power cords and tools are in use.

• UPC Code: 037332140067
• Nominal Input Voltage(s) Supported: 120V AC
• Recommended Electrical Service: 120V (110-125V)
• Input Cord Gauge Type: 14 gauge; SJT
• Input Cord Gauge (AWG): 14
• Voltage Compatibility (VAC): 120
• Maximum Surge Amps: 120000
• Input Plug Type: NEMA 5-15P
• Input Cord Details: SJT
• Input Cord Length (ft.): 25
• Right-Angle Plug: No
• Integrated Cord Clip: Yes
• Frequency Compatibility: 60 Hz
• Output Receptacles: (8) 5-15R
• Circuit Breaker (amps): 15
• Overload Protection: Combo power switch and circuit breaker
• Transformer Accommodation: (5) Yes
• Outlet Orientation: 1 bank of 5, 1 bank of 3 (transformer outlets)
• Diagnostic LED(s): Yes
• Switches: Lighted on/off power switch
• Diagnostic LED Details: 1 green "protected" LED confirms surge suppression is present
• AC Suppression Joule Rating: 3900
• AC Suppression Response Time: < 1 ns
• Protection Modes: Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
• UL1449 Let Through Rating: 400 L-N, 400 L-G, 500 N-G
• EMI / RFI Filtering: Up to 20 dB
• Automatic Shut-Off: Yes
• Network (Ethernet) Protection: No
• Material of Construction: Metal
• Power Cord Color: Yellow
• Housing Color: Black; Yellow
• Mounting Holes or Slots: Yes
• Slot or Hole Mount Measurement (Center to Center): 145 mm
• Outlets Measurement (Center to Center): Distance between standard outlets = 25.40mm; Distance between standard and transformer outlets = 50.80mm
• Receptacle Color: Black
• Shipping Dimensions (hwd / in.): 12.50 x 2.40 x 9.00
• Shipping Weight (lbs.): 5.20
• Unit Dimensions (hwd / in.): 10.260 x 5.130 x 1.570
• Unit Weight (lbs.): 4.52
• Product Certifications: cUL Listed; UL 1449; UL Listed
• Product Compliance: RoHS
• Product Warranty Period (Worldwide): Lifetime limited warranty
• Connected Equipment Insurance (U.S., Canada & Puerto Rico): $100,000 Ultimate Lifetime Insurance

Product Tags

Tripp Lite, Surge Protector Strip, 8 Outlet, 25FT Cord, 3900 Joules, OSHA, Metal Housing
