EXTENDER GIGABIT CAT5E/CAT6/CAT7
HARDWARE
Cabling
Cat 5e UTP or better
Ports
4

PERFORMANCE
Max Distance
100 m / 330 ft
Maximum Data Transfer Rate
1 Gbps (LAN)
480 Mbps (USB)

CONNECTOR(S)
Local Unit Connectors
1 - USB B (4 pin) Female
1 - RJ-45 Female
Remote Unit Connectors
1 - RJ-45 Female
4 - USB Type-A (4 pin) USB 2.0 Female

SOFTWARE
OS Compatibility
OS Independent, No additional drivers or software required

SPECIAL NOTES / REQUIREMENTS
System and Cable Requirements
Available USB port

INDICATORS
LED Indicators
1 - Power
1 - Link
1 - Host
1 - Activity
1 - RJ45 Link
1 - RJ45 Activity

POWER
Center Tip Polarity
Positive Input Current
0.6 A Input Voltage
100 - 240 AC Output Current
1 A Output Voltage
24 DC Plug Type
M Power Consumption (In Watts)
24 Power Source
AC Adapter Included

ENVIRONMENTAL
Humidity
20 - 80% RH Operating Temperature
0^oC to 50^oC (32^oF to 122^oF) Storage Temperature
-10^oC to 60^oC (14^oF to 140^oF)

PHYSICAL CHARACTERISTICS
Color
Black
Material
Steel

Product Tags

USB 2.0 HUB OVER IP NETWORK EXTENDER KIT; CONNECT 4 DEVICES @480MBPS VIA GIGABIT
