- Amplified SIP endpoint or multicast IP paging for: schools, hospitals,retail stores, office spaces, etc
- Provide background music and sound masking
- Make standard and/or emergency SIP phone calls via hands free talk-back speaker
- Background music and emergency calls for elevator applications retail stores, office spaces, etc
- Mount in the ceiling above the door and use the existing door bell switch to activate a call
- SIP compliant (see page two for list of compatible SIP servers and IP phone systems)
- Outbound Proxy, Authentification ID, Per to Peer, VLAN Tagging
- PoE powered (class 3, <13 Watts)
- Up to 28 second ID announcement (uploaded from wave file or recorded live)
- Paging prioritization
- Plays audio from multicast
- SIP endpoint or multicast group member
- Supports up to 10 multicast paging groups
- Add an optional SL-2 blue, green, red or amber strobe light (see DOD 242)
- Blue call status LED indicator
- Automatic Noise Canceling (ANC) feature for operation in noisy environments
- Viking's proprietary VOX switching eliminates the need for "Push to Talk" mode
- Selectable auto-answer feature for monitoring
- Autoprovisioning via Viking programming software
- Built-in high efficiency 6 Watt class D amplifier
- Can drive up to 5 external analog speakers for greater coverage
- Relay for activating door locks, strobe lights, external amplifiers, etc.
- SIP/Multicast: SIP page, SIP page and zoned multicast stream, zoned multicast receive
- Support for access code to prevent unwanted SIP calls
- Line-level audio output for connecting to an external amplifier
- Hangs up on: busy signal, time-out, or touch tone command
- Network remote speaker volume control
- Mounting: Drop mounts into 2 x2 or 2 x 4 suspended ceilings
- Heavy duty back box protects speaker and circuitry against plenum dust
- Automatic Gain Control (AGC) to automatically increase ring volume to compensate for ambient noise
- Diagnostics for testing microphone, speaker and relay
- Programmable pre page alert tone
An auxiliary switch input allows for a hard wired wall mounted button to initiate a SIP call. A momentary button press will initiate a standard call and holding the button for 3 or more seconds will initiate an emergency call. The integrated high sensitivity microphone enables talk-back and also monitors room noise to automatically increase the speaker volume when necessary. Line level audio output connections are provided for connecting to an external amplifier. The 22TB-IP has an integrated 6 Watt amplifier allowing its speaker output connections to directly drive up to 5 additional analog speakers. A programmable relay output is provided for activating door locks, strobe lights, external amplifiers, etc. A programmable blue status LED is provided to indicate paging, SIP call and network registration. FeaturesFor SIP Endpoint or Multicast PagingSIP compliant (see page two for list of compatible SIP servers and IP phone systems)PoE powered (class 3, Up to 28 second ID announcement (uploaded from wave file or recorded live)Paging prioritizationPlays audio from multicastSIP endpoint or multicast group memberSupports up to 10 multicast paging groupsAdd an optional SL-2 blue, green, red or amber strobe light (see DOD 242)Blue call status LED indicatorAutomatic Noise Canceling (ANC) feature for operation in noisy environmentsViking’s proprietary VOX switching eliminates the need for "Push to Talk modeSelectable auto-answer feature for monitoringAutoprovisioning via Viking programming softwareBuilt-in high efficiency 6 Watt class D amplifierSpecificationsPower: PoE class 3 (Ope- SKU: JLRS33726
