The NEWMAR 30 Amp Double Pole Circuit Breaker is designed for both AC and DC systems, ensuring reliable and safe operation. This breaker is UL recognized and CSA listed, meeting the USCG requirements for circuit protection.

Compatible with all NEWMAR electrical panels and most other brands, it features a magnetic-hydraulic 'trip-free' mechanism for enhanced safety.

Specifications:

• Rated for 5-30 amps at 65 VDC or 277 VAC; 40 and 50 amps at 32 VDC or 120 VAC.
• Mounting screws are not included; order separately.
• #10 screw terminals on the rear for easy wiring.

Available Options:

• Toggle handles in red, white, or black.
• Single pole options: 5, 10, 15, 20, 25, 30, 40, or 50 amp.
• Double pole options: 15, 20, 30, or 50 amp.

Important Note: Breakers rated above 30 amps are suitable for use in 230 VAC Line-to-Line systems, but not for 230 VAC line-to-neutral systems.

• UL recognized and CSA listed
• Magnetic-hydraulic trip-free mechanism
• Compatible with various electrical panels
• Easy wiring with #10 screw terminals
• Multiple amp ratings available
