Newmar 14AH Uninterruptible Power Supply

The Newmar 14AH Uninterruptible Power Supply provides reliable 12V DC power with built-in backup batteries that maintain operation during AC power outages. Perfect for commercial vessels, workboats, and yachts, this power supply ensures critical communication equipment remains powered when it's most needed.

Designed to support sensitive electronics with a low ripple 10-amp output, the unit floats and charges one or two internal 7-amp/hour backup batteries. During normal operation, the AC supply keeps the batteries charged, and in an outage, they automatically take over, providing uninterrupted power.

Key Features:

• Highly regulated, low ripple 12V output for noise-free operation
• Built-in stand-by battery offers immediate backup power
• Conversion capability from 7AH to 14AH model with internal mounting
• Visual indicators for normal operation and backup power
• Audible low battery indicators with mute switch
• Automatic low battery voltage disconnect
• Over-voltage and current limit protection
• Input/output fusing for enhanced safety
• Terminals for charging external batteries
• Dual voltage input (115/230 VAC) selectable via rear panel switch

Specifications:

• Battery Capacity: 14 amp/hour
• Dimensions (H x W x D): 5.3 x 9.0 x 10.5 inches
• Weight: 24 lbs.
• Input Voltage: 115/230 VAC, 50-60 Hz
• Output Voltage: 13.6 VDC @ 5A continuous, 10A intermittent
• Operating Temperature: 0-40 degrees C

The Newmar 14AH model provides optimized power management, allowing users to run essential equipment without interruption. Be prepared for power outages and maintain communication with this reliable power supply.

• Highly regulated and noise-free 12V output
• Immediate backup power during AC power loss
• Internal space for 14AH model conversion
• Indicator lights for operational status
• Low battery warning system
• Over-voltage and current protection
• Fused inputs and outputs for safety
• Options for external battery connection
• Switchable input voltage settings
