FCI Busbar - 14 Position, 150A, IP68

This 14 Position FCI Busbar is engineered for robust performance in challenging environments. Designed for compatibility with FCI connectors, it offers secure wiring solutions ideal for marine, heavy equipment, and mobile installations facing severe vibration and moisture.

The busbar is built with high-grade materials for exceptional corrosion resistance, ensuring stable conductivity even in harsh conditions. Its resilient design minimizes the need for maintenance while providing reliable long-term operation.

Compact and user-friendly, this busbar simplifies the wiring process while safeguarding critical power circuits in demanding applications.

Specifications:

• Current Rating: 150A at 48V DC
• Number of Positions: Male 14 Positions
• Wire Gauge Range: 20 AWG to 12 AWG
• Terminal Size: 2.8 mm
• Housing Material: Polyamide (PA)
• Sealing Protection: IP68
• Temperature Rating: -40°C to +125°C
• Input Connector: Male 54201415
• Mate Connector: Female 54201411
• Plate Thickness: 2mm Copper, tin-plated
• Stud: Stainless Steel 3/8"
• Base: RETPU Overmolded
• Mounting Holes (4): 0.20"

• Corrosion-resistant construction
• Stable conductivity in moisture-prone areas
• Easy installation and compact design
• Designed for high-performance applications
• IP68 sealing for maximum protection
