Technical InformationApplication/Usage: Data Networking, Optical NetworkInterfaces/PortsInterfaces/Ports Details: 1 x 1000Base-LX NetworkMedia & PerformanceMedia Type Supported: Optical FiberFiber Mode Supported: Single-modeEthernet Technology: Gigabit EthernetNetwork Technology: 1000Base-LXMiscellaneousCompatibility: D-Link DIS-100G Series Industrial Gigabit Unmanaged Switches
Features
Hot Pluggable
MSA Compliant
RoHS Compliant
Standard
Compliant Standard:IEEE802.3z
1000BASE-LX
Transceiver Type:SFP
Fiber Channel FC-PI standard:100-SM-LC-L
Fiber Media support:Single-Mode
Distance:10km
Speed
1.25Gbps
Interface
Connector:Duplex LC Connector
Single/bi Direction:Single-direction
Wavelength:1310nm
Output Optical Power (TX Optical Power):MAX.: -3dBm
MIN.: -8 dBm
Input Optical Power (RX Optical Power):MAX.: - 3 dBm
MIN.: - 24 dBm
Sensitivity:-24dBm
Cable Type:Single-mode 9/125um fibre
Operating
Power:3.3V
Max Input Current:300mA
Power Budget (MIN Power Budget):16dB
MAX Power Budget:21dB
Heat Generated:2.376 kJ/h
MTBF (hours):223,857 hours
Physical and Environment
Operation Temperature:-40 to 85^oC
Storage Temperature:-40 to 85 ^oC
Humidity (Operating):5% to 95%
Humidity (Storage):5% to 95%
Bail latch colour:Blue
Emission (EMI) and Safety Certifications
EMI:CE
FCC
VCCI
Safety:LVD
EN 60825-1
EN 60825-2
Item Dimension (L inchxW inchxH inch)
6 x 3 x 2 Weight
1.00lb Warranty Information
2 year limited

Product Tags

D-Link Networking DIS-S310LX 1000BASE-LX Singlemode SFP Optical Transceiver -40 t/+85C Brown Box
