Actisense PRO-MUX-2 Multiplexer

The PRO-MUX-2 is an intelligent NMEA 0183 multiplexer designed for optimal performance on larger leisure vessels and commercial shipping. It features a rugged stainless steel housing complemented by complete isolation on all inputs and outputs. With eight OPTO-isolated NMEA 0183 inputs, six ISO-Drive isolated outputs, a bi-directional serial port, and an Ethernet port, this device enhances network customization and device protection.

This multiplexer allows the routing of any input to any output, providing incredible flexibility for managing multiple instruments' data. Typical uses include integrating several GPS, AIS, wind, and depth devices on a single connection to a display or NMEA 2000 system using an NGX converter.

Users benefit from advanced filtering and monitoring capabilities, enabling detailed control over instrument data. Configuration is straightforward using Actisense software, accessible via a standard web browser without compatibility issues.

• 8 OPTO-isolated NMEA 0183 inputs
• 6 ISO-Drive NMEA 0183 outputs
• Bi-directional isolated serial port for additional NMEA 0183 input/output
• Ethernet port for configuration and diagnostics
• Configurable input and output baud rates
• Alarm output (N/O and N/C contacts)
• 2 independent Autoswitch virtual inputs with priority
• Advanced sentence-based filtering/routing
• Diagnostic LEDs on inputs and outputs
• Easy installation with pluggable connectors
• DIN rail or panel mountable
• Web-based configuration tool for easy setup
