Blue Sea 5029 ST Blade Fuse Block w/Cover - 12 Circuit w/o Negative Bus

Name: 5029 Blue Sea 5029 ST Blade Fuse Block w/Cover - 12 Circuit w/o Negative Bus
Brand: Blue Sea Systems
SKU: N5JTP5569R
Price: 52.57 USD
Availability: InStock

MFG No: 5029
SKU No: N5JTP5569R
UPC: 632085050290
MFG. Name: Blue Sea Systems
Available: 78
Condition: New

$36.88

Blue Sea Systems ST Blade Fuse Block - 12 Circuits with Cover

Model: 5029-BSS

Positive distribution bus with #10-32 stud
Can be used for 24-hour circuits
Cover satisfies ABYC/USCG requirements for insulation, incorporates an easy to open push button latch providing easy access to fuses, storage for two spare fuses, and label recesses that accept Blue Sea Systems" Small Format Labels for circuit identification
Fuse blocks with covers include 20 write-on circuit labels
Tin-plated copper buses and fuse clips
Accepts ring or snap fork type terminals
Accepts ATO® and ATC® fast acting blade fuses
Fuses sold separately

Specifications

Circuits	12
Maximum Amperage	100A per block 30A per circuit
Maximum Voltage	32V DC
Mounting	#8 Screw (M4)
Positive Bus	#10-32 Stud
Recommended Torque	24 in-lb (2.71 N m)
Screw Terminal Torque	18 in-lb (2.03 Nm)
Screw Terminal Type	#8-32 Screws with captive star lock washer

5029
ST Blade Fuse Block w/ Cover - 12 Circuit w/out Negative Bus

Clear insulating cover with label recesses accept Small Format Labels
Cover Satisfies ABYC/USCG requirements for insulation
Tin-plated copper buses and fuse clips give 30 Amperes rating per circuit
Accepts ATO and ATC fast acting blade fuses
20 write-on circuit labels included
Tin-plated copper buses and fuse clips give 30 Amperes rating per circuit
Accepts ATO and ATC fast acting blade fuses
