ES-7D Elite DC Load Center Panel

This panel is perfect for enhancing the circuit capacity of any Elite Series setup, or it can function independently as a standalone load center.

Key Features:

• AC (120/240V) or DC (12/24V) master breaker options: double pole AC 50 amp standard (30 amp optional), or single pole DC 100 amp standard (50 or 75 amp optional)
• Supports 16 branch circuits with 12 installed standards: ES-7A: 2-10A, 5-15A, 5-20A; ES-7D: 2-5A, 3-10A, 5-15A, 2-20A

Specifications:

• Dimensions (W x H x D): 5.25 x 15 x 4 inches
• Weight: 7 lbs (3.2 kg)

Note: The 50-amp master breaker is suitable for 230 VAC line-to-line systems, whereas for line-to-neutral systems, a maximum of 30 amps is recommended.

• Compatible with both AC and DC systems
• Expandable circuit capacity
• Supports multiple branch circuit configurations
• Lightweight and compact design
• Versatile installation options
