1U rack-mount UPS offers complete power protection for small network applications, including telecom, security and digital signage.

• UPC Code: 037332119247
• UPS Type: Line-Interactive
• Input Phase: Single-Phase
• Rated input current (Maximum Load): 10A
• Nominal Input Voltage(s) Supported: 120V AC
• UPS Input Connection Type: 5-15P
• Input Circuit Breakers: 10A
• UPS Input Cord Length (ft.): 10
• Recommended Electrical Service: 15A 120V
• Output Capacity (VA): 500
• Output Capacity (kVA): 0.5
• Output Capacity (Watts): 300
• Output Capacity (kW): 0.3
• Output Capacity Details: 4.2A @ 120V. (LINE MODE) 120% @ 5 minutes; (BATTERY MODE) 120% @ 5 seconds
• Power Factor: 0.6
• Nominal Voltage Details: 120V sinusoidal in line mode and 120V PWM in battery mode
• Frequency Compatibility: 60 Hz
• Frequency Compatibility Details: Output is regulated to +/-0.05Hz when input frequency exceeds +/-5Hz of nominal.
• Output Voltage Regulation (Line Mode): -14%, +16%
• Output Voltage Regulation (Battery Mode): +/- 5%
• UPS Output Receptacles (Surge Suppression Only): 5 UPS outlets, 1 surge-only outlet
• Load Management Receptacles: One switchable single-outlet 5-15R load bank
• Output AC Waveform (AC Mode): Sine wave
• Output AC Waveform (Battery Mode): PWM sine wave
• Nominal Output Voltage(s) Supported: 120V
• Output Receptacles: (6) 5-15R
• Individually Controllable Load Banks: Yes
• Battery Type: Valve Regulated Lead Acid (VRLA)
• Runtime Full Load (min.): 3 min. (300W)
• Runtime Half Load (min.): 14 min. (150W)
• DC System Voltage (VDC): 12
• Battery Recharge Rate (Included Batteries): Less than 12 hours to 90%
• Battery Access: Battery access door
• Internal UPS Replacement Battery Cartridge: IMPORTANT BATTERY REPLACEMENT INFORMATION > Use Tripp Lite RBC12V-1U replacement battery for SMART500RT1U models with Series Number AG-03AA listed on the UPS nameplate (sold starting in 2021); For all prior versions of SMART500RT1U, use Tripp Lite RBC62-1U replacement battery; Contact Tripp Lite customer service for additional information
• Battery Replacement Description: Hot-swappable, user replaceable batteries
• Voltage Regulation Description: Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 90 (+-5%). Input voltage range of 90 to 139
• Undervoltage Correction: Input voltages between 90 and 105 (+-5%) are boosted by 14%
• Switches: 2 Switches control off/on power status and alarm-cancel/self-test operation
• Alarm Cancel Operation: Power-fail alarm can be silenced using alarm-cancel switch
• Audible Alarm: Audible alarm indicates power-failure, overload and low-battery conditions
• LED Indicators: 5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status
• EMI / RFI AC Noise Suppression: Yes
• AC Suppression Joule Rating: 567
• AC Suppression Response Time: Instantaneous
• Primary Form Factor: Rackmount; Tower
• Rack Height: 1U
• Included Mounting Accessory Description: Included mounting brackets provide front-rail installation in 2 or 4 post racks, plus upright tower configurations
• Installation Form Factors Supported with Included Accessories :2 post 19 inch rackmount; 2 post front mount; 4 post 19 inch rackmount; Tower
• Minimum Required Rack Depth (inches): 15
• Primary UPS Depth (mm): 286
• Primary UPS Height (mm): 44
• Primary UPS Width (mm): 440
• Shipping Dimensions (hwd / in.): 4.20 x 15.70 x 21.30
• Shipping Weight (lbs.): 19.12
• UPS Housing Material: Steel
• UPS Power Module Dimensions (hwd, in.): 1.73 x 17.32 x 11.26
• UPS Power Module Weight (kg): 7.18
• UPS Power Module Weight (lbs.): 15.84
• Unit Weight (lbs.): 15.800
• Operating Temperature Range: 32? to 104?F (0? to 40?C)
• Storage Temperature Range: 5? to 122?F (-15? to 50?C)
• Relative Humidity: 0 to 95%, non-condensing
• AC Mode BTU / Hr. (Full Load): 48
• AC Mode Efficiency Rating (100% Load): 97%
• AC Economy Mode Efficiency Rating (100% Load): 0.97
• Operating Elevation (ft.): 6561 ft. (2000 m) above sea level
• Audible Noise: 45 dBA maximum, front side 1m
• Network Management Cards: WEBCARDLX
• Network Monitoring Port Description: Supports detailed monitoring of UPS and site power conditions
• PowerAlert Software: For local monitoring via the UPS's built-in communication ports, download PowerAlert software at https://tripplite.eaton.com/products/power-alert
• Communications Cable: USB and DB9 cabling included
• WatchDog Compatibility: Supports Watchdog application, OS and hard-reboot restart options for remote applications
• Network Management Card Description: Network management card optional
• Communications Interface: DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface; USB (HID enabled)
• Transfer Time: 4-6 ms typical ( < 10 ms max)
• Low Voltage Transfer to Battery Power (Setpoint): 90
• High Voltage Transfer to Battery Power (Setpoint): 139
• Cold Start (Startup in Battery Mode During a Power Failure): Cold-start operation supported
• High Availability UPS Features: Auto Probe Monitoring and Reboot (requires WEBCARDLX); Automatic Voltage Regulation (AVR); Hot swappable batteries; Remote management; Surge/noise protection
• Grounding Details: Back panel grounding lug
• UPS Applications: High-End Desktop/Small Network; Retail/Point of Sale; Hospitality
• Product Certifications: CSA (Canada); NOM (Mexico); UL 1778
• Product Compliance: RoHS; ENERGY STAR Qualified
• Product Warranty Period (Worldwide): 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.
• Connected Equipment Insurance (U.S., Canada & Puerto Rico): $250,000 Ultimate Lifetime Insurance
