Egis XD Series Triple Flex Relay with Knobs & Tinned Wires

The Egis XD Series Triple Flex Relay combines three high-amp relays into a single, space-saving module. This innovative design not only reduces installation space but also eliminates the need for external link cables, thus enhancing reliability by preventing disconnections caused by vibrations. The system provides clear manual controls, ensuring users always know the state of the relay.

Applications:

• Ideal for replicating multi-battery switching and charge management functions; the outer relays manage dual battery loads while a central automatic charging relay ensures efficient charge sharing.
• Supports setups with multiple automatic charging relays (ACR) in one compact unit, perfect for 3-4 battery systems requiring multiple ACRs.
• Expandable with link and cross-link busbars for additional XD relays, compatible with 3 or 4 battery systems using standard busbar accessories.

Key Features:

• Durable construction with IP67/IP6K9K sealing, allowing versatile mounting options and using high-temperature materials.
• Manual control option enhances operational awareness and control state visibility compared to other solutions.
• Programmable functionality via dip switches offers flexibility for OEMs and installers.
• Space and weight reduction of 35-75% achieved through advanced bi-stable solenoid technology.
• Compatible with existing competitor products utilizing DTM/ATM connector pins for easy integration.
• Significantly lowers off-state current draw (90-95%) compared to competitive devices, optimizing performance.

Specifications:

• Total Continuous Current Amps: 500
• Max Cranking Current: 1500 Amps
• Mechanical Switching Life: 1,000,000 Cycles
• Voltage Range: 8-36 VDC
• Off-State Current Draw: 1.3 mA
• State Change Current: 5A @ 12 VDC; 3A @ 24 VDC

Additional Features:

• LED Status Display: A front-facing LED provides at-a-glance status, replicated by a remote LED.
• 3-Position Manual Override: Allows users to force each relay open or closed with lock positions.
• Circuit Label Sheet: Includes weatherproof labels for easy circuit identification.
• Protective Cover: Shields terminal studs and cable edges from accidental shorts.
• Stainless Hardware: Corrosion-resistant materials ensure longevity and reliability.
• Programmable: Easy dip switch access for custom configuration, with a handy guide included.
• Compact Design: High amp capability in a smaller footprint than typical alternatives, minimizing installation needs.
• Integrated Vent: Quality Gortex vents manage internal pressure, preventing moisture ingress.
